Jackery Manual Transfer Switch for 2000 Plus and 3600 Plus
Jackery Manual Transfer Switch for 2000 Plus and 3600 Plus
Free Shipping on Orders $100 and over!
Couldn't load pickup availability
Pre-Wired 120V 30A 6-Circuit Manual Transfer Switch for Explorer 2000 Plus & 3600 Plus
The Jackery Manual Transfer Switch (120V 30A) is a safe, reliable home backup solution designed to link your Jackery portable power station directly to your home's main electrical panel during outages. Built specifically for the Jackery Explorer 2000 Plus and Explorer 3600 Plus, this 6-circuit transfer switch safely isolates selected branch circuits—such as your refrigerator, lights, Wi-Fi router, and TV—from the utility grid, completely eliminating back-feeding risks while providing clean battery power to essential household appliances.
- Targeted Explorer Series Compatibility: Engineered specifically for seamless plug-in operation with the Jackery Explorer 2000 Plus and Explorer 3600 Plus power stations.
- 6 Dedicated Breaker Circuits: Features 6 individual, circuit-breaker-protected branch circuits to manage and back up essential 120V household loads during power blackouts.
- Completely Pre-Wired Setup: Factory pre-wired with color-coded lead wires to streamline professional installation at your breaker panel.
- Eliminates Dangerous Back-Feeding: Utility-isolation toggle switches protect line workers and prevent electrical grid interference during utility power restoration.
- Durable Indoor Metal Enclosure: Constructed with a heavy-duty metal cabinet and protective cover to shield toggle switches and breakers from dust and accidental bumps.
- Integrated Wattmeters & NEMA L5-30 Inlet: Includes color-coded analog wattmeters for real-time power monitoring and a twist-lock NEMA L5-30 inlet for secure power cable connection.
Versatile Applications
- Essential Home Backup: Powers critical 120V circuits (refrigerator, kitchen outlets, home office, lighting) directly through your existing home wiring during storm blackouts.
- Off-Grid & Cabin Power Management: Provides a neat, permanently wired connection panel for battery-based emergency power setups.
Specifications & What's Included
What's Included:
- 1x Jackery Manual Transfer Switch (120V 30A, 6-Circuit)
- 1x Integrated NEMA L5-30 Power Inlet Box
Jackery Manual Transfer Switch (120V 30A) Specifications
| Feature | Specification |
|---|---|
| Output Voltage | 120V AC |
| Max Output Current | 30A Max |
| Number of Circuits | 6 Individual Circuit Breaker Protected Circuits |
| Power Inlet Type | NEMA L5-30 Twist-Lock Inlet |
| Model Compatibility | Jackery Explorer 2000 Plus & Explorer 3600 Plus |
| Enclosure Type | Metal Cabinet with Protective Cover (Indoor Rated) |
| Monitoring | Color-Coded Analog Wattmeters |
| Wiring Type | Factory Pre-Wired |
Frequently Asked Questions
-
Which Jackery power stations are compatible with this 120V 30A switch?
This transfer switch is engineered for use with the Jackery Explorer 2000 Plus and Explorer 3600 Plus power stations.
-
How is this transfer switch installed?
The switch is wired directly to your home's main breaker box by a licensed electrician. Each of the 6 circuits connects to specific branch circuits (like kitchen, lights, or refrigerator) in your panel.
-
Can I install this manual transfer switch myself?
No. Installation requires a qualified, licensed local electrician to ensure proper wiring to your electrical panel and full compliance with local electrical codes.
-
How do I connect my Jackery power station to the switch?
Once installed at your breaker panel, you simply plug a heavy-duty 30A power cable from your Jackery power station into the built-in NEMA L5-30 inlet on the transfer switch.
-
Can this 120V 30A transfer switch run 240V appliances like well pumps?
No. This model is designed for 120V single-phase circuits only. If you need to back up 240V heavy appliances, you will need the Jackery 240V 50A Manual Transfer Switch.
