Power When and Where You Need It Most
The Jackery HomePower 3600 Pro Max is built to handle your most demanding energy needs with complete reliability 🔋. Combining a massive 3,584Wh capacity with 120V/240V dual-voltage versatility, it bridges the gap between portable battery power and whole-home energy security. Whether you are safeguarding your household against unexpected power outages, running heavy-duty machinery, or living self-sufficiently off-grid, this system seamlessly adapts to keep your essential devices and major appliances running without interruption.
⚡ Versatile Power for Every Scenario
🏠 Seamless Whole-Home Emergency Backup: Connect directly to a 50A split-phase transfer switch (MTS or ATS) for reliable emergency power. Featuring a ≤10ms automatic UPS switchover, critical home electronics stay running without interruption. The integrated 9.6kW high-power bypass allows intelligent auto-switching between generator power during peak daytime hours and silent battery power at night.
🔌 Heavy-Duty Appliances & High-Load Equipment: Powered by a robust 4,000W continuous output (8,000W peak surge) and a NEMA 14-50 240V receptacle, this unit effortlessly starts and runs high-draw appliances—such as well pumps, heavy power tools, and subpanels—alongside everyday 120V devices.
☀️ Off-Grid Power & Scalable Expansion: Harness up to 1,200W solar input to fully recharge in approximately 4 hours off-grid. As your power demands grow, expand capacity from 3.58kWh up to 21.5kWh with expansion batteries, or scale up to 43kWh and 8,000W output through a parallel connection.
Specifications & Manual
Jackery HomePower 3600 Pro Max Manual
📦 What's in the Box
- Jackery HomePower 3600 Pro Max Power Station
- AC Charging Cable
- Screw Terminal Block
- User Manual & Quick Start Guide
|
Category |
Specification |
|
Product |
Jackery HomePower 3600 Pro Max |
|
Capacity |
3,584Wh |
|
Battery Chemistry |
LFP (6,000+ cycles to 70% or more) |
|
Output Wattage |
4,000W Continuous (8,000W Peak Surge) |
|
Voltage Output |
120V / 240V Dual Voltage |
|
AC Outlets |
2x 120V (2,000W max), 1x NEMA 14-50 (240V, 4,000W) |
|
USB Outlets |
1x USB-C (100W PD), 1x USB-A (18W) |
|
AC Input |
1,800W |
|
Solar / DC Input |
1,200W Max (2x 8020 ports) |
|
UPS Speed |
10ms or less |
|
Expansion Capacity |
3.6kWh up to 21.5kWh (Up to 43kWh combined) |
|
Parallel Output |
Up to 8,000W |
|
Weight |
32 kg (70.5 lbs) |
|
Dimensions |
375 x 275 x 450 mm |
