The Jackery Battery Pack 5000 Plus is the high-capacity storage solution designed specifically for the Explorer 5000 Plus. Utilizing innovative CTB (Cell-to-Body) technology, this pack delivers a massive 5040Wh of energy in a compact, rugged frame. Whether you are prepping for extended winter outages or building a heavy-duty off-grid system, this module provides the industrial-grade scalability your setup requires.
LFP Cell-to-Body Technology | 4,000+ Cycle Life | Extreme Cold Rated (-15°C)
Professional-Grade Energy Scalability Maximize your home backup or industrial power setup with the Jackery Battery Pack 5000 Plus. By integrating seamlessly with the Explorer 5000 Plus, this expansion module allows you to store massive amounts of energy for heavy-duty appliances and long-term emergency use.
Why Expand with the 5000 Plus Pack?
Massive 5kWh Capacity: A single expansion pack adds 5040Wh of storage, significantly extending the runtime of your high-draw devices.
Next-Gen CTB Technology: The "Cell-to-Body" design integrates the battery cells directly into the chassis, creating a more space-saving, lightweight, and impact-resistant structure.
10-Year Reliability: Powered by high-stability LiFePO4 cells, this pack maintains over 70% capacity even after 4,000 charge cycles.
Cold-Weather Ready: Engineered to perform in extreme conditions, this battery functions reliably in temperatures as low as -15°C (5°F).
Smart Monitoring: Features an integrated Smart Display for real-time updates on battery health, capacity, and status.
Advanced Safety: Certified to UL1973 standards with a 12-layer BMS that includes fireproof and shockproof protections.
Specifications & Manual
⚠️ IMPORTANT NOTICE: This is an Expansion Battery Pack. It is compatible only with the Jackery Explorer 5000 Plus. It does not feature AC outlets and cannot be used as a standalone power source.
|
Category |
Specification |
|
Capacity |
5040Wh (45Ah / 112V DC) |
|
Battery Chemistry |
LiFePO4 (LFP) |
|
Cycle Life |
4000+ Cycles to 70%+ Capacity |
|
CTB Technology |
Lightweight, Space-Saving Integrated Design |
|
Weight |
81.57 lbs (37 kg) |
|
Dimensions |
16.5 x 13.5 x 13.2 in |
|
DC Expansion Input |
80.5V - 126V ⎓ 41A Max |
|
DC Expansion Output |
80.5V - 126V ⎓ 98A Max |
|
Operating Temp |
-15°C to 45°C (5°F to 113°F) |
|
Warranty |
5 Years Total |
FAQs
Can I use this pack with the Explorer 2000 or 3000 Plus? No. Due to the high-voltage architecture (112V DC), this battery pack is exclusive to the Explorer 5000 Plus system.
How many packs can I connect? Please refer to your Explorer 5000 Plus manual for specific stacking configurations to reach your desired kWh capacity.
Is it difficult to move? Despite its high capacity, the pack features an ergonomic dual-handle design designed to distribute weight evenly, making it manageable for two people or easy to stack in a permanent backup location.
Can it be left outside? The unit is IP20 rated, meaning it is protected against solid objects but should be kept in a dry, covered environment. Its discharge performance remains stable down to -15°C.
